STUDIO NEXT

$12,000 USD Regular price $12,000 MSRP Regular price $14,000

Studio NEXT V-PR with Shimano Dura Ace and your choice of race wheels.

Shipping Worldwide

EXPLORE THE DETAILS

Service Course speed, now 150 grams lighter. Lightweight Studio NEXT carbon takes the class-leading aero performance of the Service Course to the next level with our highest-grade carbon and most sophisticated carbon lay-up. We have reduced frame weight and produced a race bike with the highest stiffness-to-weight ratio we have ever achieved.

  • Frame weight: 924 grams (size M) - The Studio NEXT Service Course is one of the lightest dedicated aero road bikes on the market
  • Studio NEXT Carbon - Our highest grade carbon fiber and most sophisticated carbon lay-up reduces frame weight by 150 grams
  • Complete build: 16 lbs (Size M, SRAM RED, Zipp 454, fully painted frame and cockpit)
  • Exclusive premium Studio NEXT paint color options
  • Paint matched one-piece aero cockpits maximize aerodynamics and aesthetics
  • Aero Headtube - Extended, narrowed, and shaped to reduce frontal area and direct air rearward
  • Aero Fork - All-new fork design creates efficient airflow around the front tire
  • Aero Downtube - Deep, aggressive shape reduces turbulence and keeps airflow attached
  • Slimmed down toptube, seattube, and seatstays reduce weight
  • Wide Tire Clearance - Clearance for tires up to 36mm wide
  • UDH - Universal Derailleur Hanger for serviceability and compatibility
  • Threaded T47A BB - Silently increases stiffness, serviceability, and reliability
Size XS S M L
Stack (cm) 51.5 53.5 56 58.5
Reach (cm) 37 38 39 40
Standover height (cm) 71.1 74.3 77.5 80.9
Top tube length (cm) virtual horizontal 51.3 53.3 55.6 57.3
Seat tube angle 74.5° 74° 73.5° 73.5°
Seat tube length (cm) 41 45 48.5 52
Head tube angle 71˚ 72˚ 73˚ 73˚
Head tube length (cm) 10.2 11.9 14.4 17.1
Wheelbase (cm) 97.6 98.3 99.3 101.2
Front center (cm) 57.3 58.4 59.2 61.1
Chainstay length (cm) 41.1 41.1 41.1 41.1
Bb drop (cm) 7.4 7.4 7.2 7
Fork offset (cm) 4.7 4.7 4.7 4.7
XS
155cm 5' 1" - 168cm 5' 6"
S
163cm 5' 4" - 175cm 5' 9"
M
170cm 5' 7" - 180cm 5' 11"
L
178cm 5' 10" - 188cm 6' 2"
XL
185cm 6' 1" - 196cm 6' 5"

The amount of assembly required depends on shipping option you select. Typically our bike assembly runs between 30 to 45 minutes. Check out our shipping and delivery options to find the best option for you and your budget.

Triple check the seatpost battery/Di2 wire connection. Many times even though you think you have the wire firmly connected, give it another push and 9 times out of 10 the system comes to life.

We spec different length components on our bikes based on common lengths per each size of bike. If you are looking to specify what length components or the gearing you'd like on your new Quintana Roo just live-chat or contact us and we'll get you started on a custom order.

Absolutely. Our bikes are built to order so you can customize however you'd like. If there are components you'd really like on your bike but don't see them offered live-chat or contact us for availability and a custom quote!
