PRfour Disc

$ 3,095.00 USD $ 3,249.00 USD

Geometry Guide

PRSERIES GEOMETRY

Size	48	50	52	54	56	58.5
Seat Tube Length	48cm	50cm	52cm	54cm	56cm	58.5cm
Top Tube Length	47cm	49cm	51cm	53cm	54.5cm	56cm
Head Tube Length	7.4cm	9.5cm	11.5cm	14.2cm	15.8cm	18.4cm
Head Tube Angle	71˚	72˚	72˚	72˚	72˚	72˚
Seat Tube Angle	77 / 83˚	77 / 83˚	77 / 83˚	77 / 83˚	77 / 83˚	77 / 83˚
Chainstay Length	39.5cm	39.5cm	39.5cm	39.5cm	39.5cm	39.5cm
Wheelbase	95.7cm	96.8cm	99.5cm	101.7cm	103.1cm	105cm
Standover Height	73cm	75cm	77cm	79cm	81.5cm	84cm
Front Center	57.4cm	58.4cm	61cm	63.3cm	64.7cm	66.5cm
BB Drop	7.35cm	7.35cm	7.35cm	7.35cm	7.35cm	7.35cm
Fork Rake	4.8cm	4.8cm	4.8cm	4.8cm	4.8cm	4.8cm
Stack	48cm	50cm	52cm	54cm	56cm	58.5cm
Reach	38cm	39cm	41cm	42.5cm	43.5cm	44.5cm

XY FIT COORDINATES FOR PRSERIES BIKES

DOWNLOAD PRSIX SERIES FIT COORDINATES | DOWNLOAD PRFIVE & PRFOUR SERIES FIT COORDINATES

Financing Options

LOOKING FOR A CUSTOM PAINT AND DECAL COMBINATION?

Make a custom bike builder appointment or chat with us now about an upgrade.

INTERNATIONAL ORDERS:

Price excludes any applicable VAT, duties and custom import fees.

LEARN ABOUT THE ADVANTAGES OF DISC BRAKES

PRFOUR DISC

Featuring the same aerodynamic frame shape as our pro level PRsix2 Disc superbike, the stopping power and control of disc brakes, the PRfour Disc is the most affordable and technologically advanced disc brake triathlon bike available to triathletes.

We developed the PRfour Disc featuring a mix of Shimano 105 11-speed components with TRP Spyre mechanical disc brakes for real triathletes looking for disc brake advantages at a price they can afford, without sacrificing performance or reliability.

Not only do disc brakes add to the stopping power and consistency of braking in any condition, they also increase the lateral stiffness and stability of the bike with the addition of oversized thru-axles. With the combination of QR's wind-tunnel developed SHIFT+ technology, boat-tail airfoils and leading edge absent chainstay, the PRfour Disc gives you the ability to bike faster, efficiently output more power, and conserve energy for the run. It's designed with a standard front end, no crazy integrations, making the PRfour Disc easier to mechanically work on and travel with. Plus, stand out and choose between four ultra-bright graphic colors on a stealthy matte black frame!

An all-out race bike at an affordable price—the PRfour Disc gives athletes the confidence they need to perform their best and set new PR's.

For use in a stationary trainer, a specific thru-axle adapter will need to be ordered. The rear thru-axle is an E-thru standard M12x1.5, 142mm long. The adapter will be specific to the trainer you own, so please check with the trainer manufacturer if you have any questions.

Key Advantages

24/30T hybrid composite technology
Trickle-down technology from the PRsix & PRfive
SHIFT+ technology
Boat tail cross sections
Leading edge absent chainstay
Static downtube orientation
12mm thru-axle design
QBox aero rear storage
QR Top Tube Storage System
QR Perfect Position Carbon Seatpost
Easy assembly and maintenance: 2 allen wrench sizes
Fit-Ready option available
QR Lifetime Warranty
Order online direct with full-assembly ProBox, through a QR retailer or choose Home.Delivery.Rightat checkout

Component Specs
Drivetrain Upgrades
Wheelset Upgrades
Product Reviews
Shipping & FAQ
Reviews

We pair each Quintana Roo frame with some of the best components and drivetrains in the world. We take component specifications seriously, as the quality and performance of the components are just as important as the frames we design and produce.

Looking for a specific crank length, saddle or gearing on your new QR bike? Chat with us or contact us now! Additional charges may apply.

Shimano 105 Premium Mix

Fork	QR Aero Disc Carbon
Headset	Cane Creek IS41
Stem	Profile Seventeen
Handlebars	Profile Design Wing 10A with 35A Extensions
Seatpost	QR Aero Carbon
Saddle	ISM PS 1.0
Shifters	Micro Shift
Front Derailleur	Shimano 105
Rear Derailleur	Shimano 105
Brakes	TRP Spyre

Disc Rotors	TRP 25 Centerlock 160mm
Crankset	Shimano 105 R7000 52/36
Cassette	Shimano 105 11-30
Chain	Shimano 105
Bottom Bracket	T47
Tires	Continental Ultra Sport III 25c
Wheelset	Select Wheels Above
Top Tube Storage	QR Top Tube Storage System
QBox	QR QBox
Riser Kit	15mm Profile Design Riser Kit Included

Bar, Stem & Crank Specs

Stem Length	Size 48-50 — 70mm	Size 52-54 — 90mm	Size 56-58.5 — 110mm
Crank Length	Size 48-52 — 165mm	Size 54-56 — 170mm	Size 58.5 — 172.5mm
Bar Width	Size 48-52 — 42cm	Size 54-56 — 42cm	Size 58.5 — 42cm

SHIMANO 105
"Taking pleasure to every rider". 105 is supporting every rider who achieves his personal goals for everyday training and long rides during the weekends, and riding with friends. The best balance of 105 brings pleasure to every rider with the trusted reliable performance. 105 will give every rider a sense of satisfaction, pleasure and fulfillment with advanced functionality, smoothness and ergonomics.
HED Vanquish RC6 Performance
The co-developed Vanquish RC6 Performance wheelset takes QR’s disc-brake triathlon bikes to the next level of performance. Made in HED’s Minnesota factory, the Vanquish RC6 Performance undergoes an in-depth quality control process. The proprietary wheels use the same patented rim shape that HED uses for all of its disc-specific wheelsets. The RC6 Performance shape is all-new, with a 30mm external width (21mm internal width). This results in a superior aerodynamic performance with 23-28mm tires.

REYNOLDS AR 58/62 DISC
The Reynolds AR58/62 disc brake carbon road bike wheelset provides the ultimate aerodynamic advantage for time trials and triathlons. The tubeless-ready rims are individually optimized for front and rear. The front is narrower to reduce frontal area and shaped to deliver stable crosswind handling. The rear is built with a 21mm rim channel to fit wider tires for reduced rolling resistance and the 61mm heights provides maximum lift to sail through the wind. The Reynolds AR58/62 Disc come with Reynold's lifetime warranty.

SHIMANO RS170 DISC
The Shimano RS170 offers excellent rolling performance and is designed to provide the highest levels of braking performance thanks to the disc brake system. Equipped with the Shimano Centre Lock disc brake technology, this wheel will supply the rider with fast acceleration, stability and stiffness, combined with exceptional braking control.
Find answers to common questions about bike builds, custom component selections, and shipping below. If you have any questions feel free to live-chat with us or contact us.

SHIPPING & DELIVERY OPTIONS

Shipping & Delivery Options Shipping FAQs

FREQUENTLY ASKED QUESTIONS

Can I make changes to the build kit?
Absolutely. Our bikes are built to order so you can customize however you'd like. If there are components you'd really like on your bike but don't see them offered live-chat or contact us for availability and a custom quote!

Can I have a different length stem, crankarms, or different gearing?
We spec different length components on our bikes based on common lengths per each size of bike. If you are looking to specify what length components or the gearing you'd like on your new Quintana Roo just live-chat or contact us and we'll get you started on a custom order.

I received my Di2 bike, but the system isn't charging?
Triple check the seatpost battery/Di2 wire connection. Many times even though you think you have the wire firmly connected, give it another push and 9 times out of 10 the system comes to life.

What kind of thru-axle do I need for my stationary trainer?
For use in a stationary trainer, a specific thru-axle will need to be ordered. The rear thru-axle is an E-thru standard M12x1.5, 142mm long.

Does my bike arrive assembled?
The amount of assembly required depends on shipping option you select. Typically our bike assembly runs between 30 to 45 minutes. Check out our shipping and delivery options to find the best option for you and your budget.

PRfour Owner Guide

Need help assembling, adjusting, or maintaining your PRfour? Check out our guide with self-help instructions.

Owner Guide

QR SHIPPING PROBOX: EASY DELIVERY + ASSEMBLY

Other Helpful Videos
Click here to read Dan Empfield's, of Slowtwitch, PRfour Disc review.

"I feel that the number of relevant bike brands in no-draft triathlon have whittled down to 8. Quintana Roo is one of those relevant brands. In fact, if you narrowed the brand list to 4, it’d make the cut. This new bike, the PRfour Disc, is an advertisement for why that is. This is a disc brake triathlon bike complete for under $3,000."

PRSERIES GEOMETRY

Size	48	50	52	54	56	58.5
Seat Tube Length	48cm	50cm	52cm	54cm	56cm	58.5cm
Top Tube Length	47cm	49cm	51cm	53cm	54.5cm	56cm
Head Tube Length	7.4cm	9.5cm	11.5cm	14.2cm	15.8cm	18.4cm
Head Tube Angle	71˚	72˚	72˚	72˚	72˚	72˚
Seat Tube Angle	77 / 83˚	77 / 83˚	77 / 83˚	77 / 83˚	77 / 83˚	77 / 83˚
Chainstay Length	39.5cm	39.5cm	39.5cm	39.5cm	39.5cm	39.5cm
Wheelbase	95.7cm	96.8cm	99.5cm	101.7cm	103.1cm	105cm
Standover Height	73cm	75cm	77cm	79cm	81.5cm	84cm
Front Center	57.4cm	58.4cm	61cm	63.3cm	64.7cm	66.5cm
BB Drop	7.35cm	7.35cm	7.35cm	7.35cm	7.35cm	7.35cm
Fork Rake	4.8cm	4.8cm	4.8cm	4.8cm	4.8cm	4.8cm
Stack	48cm	50cm	52cm	54cm	56cm	58.5cm
Reach	38cm	39cm	41cm	42.5cm	43.5cm	44.5cm

XY FIT COORDINATES FOR PRSERIES BIKES

DOWNLOAD PRSIX SERIES FIT COORDINATES | DOWNLOAD PRFIVE & PRFOUR SERIES FIT COORDINATES

QR EXCLUSIVE FIT-READY™

With Quintana Roo’s Fit-Ready™, you’ll be ready to ride—and race—the moment you receive your new QR, in a way no other company can provide. Learn more about our exclusive Fit-Ready™ service.

Fit-Ready FAQs
